LITHIUM CHARGE CART SOLUTION FOR CLASS 8 TRUCKS
Left unattended, sulfation builds up, capacity is robbed, and batteries die in a week. TruckBoost™ recharges and rejuvenates batteries, getting your trucks back on the road fast and extending battery service life.
One of the biggest maintenance headaches for trucking fleets is starting batteries. While it’s easy to blame the battery manufacturer, most battery failures are caused by neglect or improper maintenance.
While lead acid batteries are relatively cheap and safe, they are imperfect. Any lead acid battery left in a low state of charge will form a coating of sulfate on the positive plate that will interfere with charging and discharging. This immobile hard sulfate on the plate also means less sulfuric acid in the battery. Both factors combine to rob the batteries of starting power and reserve energy to power driver hotel accessories.
TruckBoost™ is packed with power and ready to replenish batteries for unattended trucks in the yard. With 5 kW-h battery energy on board, the system can supply up to 175 amps of jumpstart power for truck starter batteries, allowing quick and efficient return to service after yard stays or routine maintenance of trucks parked for storage.
TruckBoost™ helps break up plate sulfation and restore battery capacity without the damage caused by uncontrolled high-voltage charging.
The system provides a reliable, at-the-ready source of power for jumpstarts, deep charging, and maintenance in yard and storage environments.
| Cell type | LiFePO4 |
|---|---|
| Rated Energy Storage | 5 kW·h |
| Cell operation temp (charging) | 40°F to 125°F (5°~50°C) |
| Cell operation temp (discharging) | -5°F to 150°F (-20°~65°C) |
| Storage temp range (<1 month) | -5°F to 140°F (-20°~60°C) |
| Storage temp range (<6 months) | 15°F to 115°F (-10°~45°C) |
| BMS | Protect against Out of Range I/O |
| Self-Discharge | <2% per month |
| Operating humidity range | 10%~90% RH |
| Shipping class | UN3480 |
| Cycle life | >3000 (0.5C charge and discharge) |
| Heating element | Not required |
| Max Output Power [kW] | 2.5 kW |
|---|---|
| Output Amperage [A] | 175 Amps |
| Rated output voltage [V] | 14.7 VDC |
| Charging Mode Bulk CC | 175 A |
| Storage temp range (<1 month) | -5°F to 140°F (-20°~60°C) |
| Operating humidity range | 10%~95% RH |
| Input Voltage [VAC] | 90 to 264 |
|---|---|
| Max Power [kW] | 1.5 kW |
| Input Current (max) [A] | 13 Amps |
| Operating humidity range [rh] | 10%~95% RH |
TruckBoost™ gives your fleet a compact, efficient way to recover weak batteries and return trucks to service quickly. The system reduces downtime, improves yard maintenance, and helps sustain starting battery health in high-use fleet operations.
Customers served include large fleets, truck dealerships, leasing companies, maintenance facilities, and truck storage areas.
